N2XS(F)2Y N2XSY Four Core MV Power Cable With Copper Conductor PVC Insulated

N2XS(F)2Y N2XSY Four Core MV Power Cable With Copper Conductor PVC Insulated
N2XS(F)2Y N2XSY Four Core MV Power Cable With Copper Conductor PVC Insulated

Large Image :  N2XS(F)2Y N2XSY Four Core MV Power Cable With Copper Conductor PVC Insulated

Product Details:
Place of Origin: Hebei，China
Brand Name: Zhongdong
Certification: IEC,CE,ISO,TUV
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Rolls, Wooden Drums, Steel Drums, Reels or customized
Delivery Time: 7-30 days based on different qty
Payment Terms: ,L/C,T/T
Supply Ability: 100KM/Week
Contact Now

N2XS(F)2Y N2XSY Four Core MV Power Cable With Copper Conductor PVC Insulated

Description
Voltage: 0.6/1kV Insulation: PVC
Jacket: PVC No Of Core: 3
Highlight:

PVC Insulated MV Power Cable

,

Four Core MV Power Cable

N2XS(F)2Y / N2XSY  Low Voltage Cable Four Core Power Cable Copper Conductor PVC Insulated





Application



N2XSYd is a medium-voltage power cable widely used in industrial and utility electrical networks. Its primary applications include:

  1. ‌Power distribution systems‌: Transmits electrical energy in underground or cable-tray installations.
  2. ‌Industrial plants‌: Supplies power to heavy machinery, transformers, and substations.
  3. ‌Renewable energy projects‌: Integrates into wind farms, solar parks, and grid connections requiring robust shielding.
  4. ‌Urban infrastructure‌: Deployed in underground networks for public utilities, hospitals, and commercial complexes.
  5. ‌High electromagnetic interference (EMI) environments‌: Ideal for areas with strong EMI due to its double-layer shielding.



N2XS(F)2Y N2XSY Four Core MV Power Cable With Copper Conductor PVC Insulated 0N2XS(F)2Y N2XSY Four Core MV Power Cable With Copper Conductor PVC Insulated 1N2XS(F)2Y N2XSY Four Core MV Power Cable With Copper Conductor PVC Insulated 2





Construction



  1. ‌Conductor‌: Plain or stranded copper (Class 2) for efficient current carrying.
  2. ‌Insulation‌: Cross-linked polyethylene (XLPE) rated for ‌12/20 kV‌ (up to ‌24/36 kV‌ variants), offering high dielectric strength and thermal stability.
  3. ‌Shielding‌: Inner layer‌: Copper wire braid for electromagnetic shielding.  Outer layer‌: Copper tape or longitudinally applied metal screen for additional protection against external interference.
  4. ‌Sheath‌: Flame-retardant PVC (ST2 type) or LSZH (low-smoke zero-halogen) options, resistant to moisture, oils, and abrasion



Specification

No.of cores and
crosS-section area		 Nominal thickness Overall
Diameter

(approx)		 Weight of
cable

(approx)		 DC Resistance
at 20℃

Insulation min		 Current Carrying
Capacity at 30℃		 Short circuit
current of
conductor at
1.0 sec		 Standard
Delivery length
Insulation Outer sheath In AIR In GROUND
sq.mm   mm mm Kg/Km MQ.km   A kA m
4x1.5 re 0.7  1.8  15  302  1,120 21  28  0.26  1,000
4x1.5 rm 0.7  1.8  15  307  1,020 21  28  0.26  1,000
4×2.5 re 0.7  1.8  15  329  940  29  37  0.41  1,000
4x2.5 rm 0.7  1.8  15  345  842  29  37  0.41  1,000
4x4 re 0.7  1.8  16  410  784  39  46  0.64  1,000
4x4 rm 0.7  1.8  17  425  704  39  46  0.64  1,000
4x6 re 0.7  1.8  17  510  667  49  59  0.93  1,000
4×6 rm 0.7  1.8  18  542  590  49  59  0.93  1,000
4x10 re 0.7  1.8  19  703  538  68  78  1.53  1,000
4×10 rm 0.7  1.8  20  750  473  68  78  1.53  1,000
4x16 rm 0.7  1.8  23  1,045 392  91  101  2.41  1,000
4x25 rm 0.9  1.8  27  1,534 400  119  132  3.73  1,000
4x35 rm 0.9  1.8  30  1,995 348  148  157  5.18  1,000
4x50 rm 1.0  1.9  34  2,702 326  181  187  7.36  1,000
4×50 sm 1.0  1.9  30  23,010 326  181  187  7.36  1,000
4x70 rm 1.1  2.0  40  3,745 303  227  233  10.26  1,000
4x70 sm 1.1  2.0  36  3,345 303  227  233  10.26  1,000
4x95 rm 1.1  2.2  45  5,025 262  278  278  13.88  500
4x95 sm 1.1  2.2  40  4,450 262  278  278  13.88  500
4x120 rm 1.2  2.3  50  6,225 254  324  324  17.49  500
4x120 sm 1.2  2.3  44  5,555 254  324  324  17.49  500
4x150 rm 1.4  2.5  55  7,652 266  370  358  21.81  500
4x150 sm 1.4  2.5  49  6,810 266  370  358  21.81  500
4×185 rm 1.6  2.6  61  9,485 271  420  403  26.86  500
4x185 sm 1.6  26  54  8,410 271  420  403  26.86  500
4×240 rm 1.7  2.9  68  12,195 252  495  475  34.78  200
4x240 sm 1.7  2.9  60  10,895 252  495  475  34.78  200
4x300 rm 1.8  3.0  76  15145  240  568  528  43.41  200
4x300 sm 1.8  3.0  65  13460  240  568  528  43.41  200
