Screened Single Core Cable Medium Voltage PVC Sheathed N2XSRY N2XSERY

Large Image : Screened Single Core Cable Medium Voltage PVC Sheathed N2XSRY N2XSERY

Product Details:

Place of Origin:	Hebei，China
Brand Name:	Zhongdong
Certification:	ISO,CE,IEC,TUV
Model Number:	YJV32

Payment & Shipping Terms:

Minimum Order Quantity:	Negotiable
Price:	Negotiable
Packaging Details:	Wooden Drum
Delivery Time:	10work days
Payment Terms:	L/C,T/T
Supply Ability:	100KM/Week

Contact Now

Screened Single Core Cable Medium Voltage PVC Sheathed N2XSRY N2XSERY

Description

Insulation Material:	Xlpe	Conductor Material:	Aluminum/copper
Sheath:	PVC	Armour:	SWA
Standard:	IEC Standard	Type:	Medium Voltage
Highlight:	Single Core Cable Medium Voltage , PVC Sheathed N2XSERY Cable , N2XSRY Single Core Cable

Screened Single Core Medium Voltage Power Cables PVC Sheathed N2XSRY N2XSERY

Application

For laying indoors, in tunnel, cable trench, well or direct in ground, able to bear external mechanical forces and certain pulling force

Construction

Conductor:Class 2 Aluminium/Copper circular, stranded
Conductor Screen:Semi-conductive XLPE (Cross-Linked Polyethylene)
Insulation :XLPE (Cross-Linked Polyethylene)
Insulation Screen :Semi-conductive XLPE (Cross-Linked Polyethylene)
Metallic Screen :Copper wire screen
Tape Plastic tape is applied over the screen
Filler Extruded polymeric material
Bedding PVC (Polyvinyl Chloride)
Armour :SWA (Galvanized Steel Wire Armoured)
Sheath :Extruded PVC (Polyvinyl Chloride) type ST2


Product parameters for Three cores6/10kV(6.35/11kV) product parameters for three cores steel wire armored armored

			Specification

			Outer diameter

			Approx. outer diameter of cable

			Approx. weight of cable

			Max. D.C. resistance of conductor at 20℃

			mm2

			mm

			mm

			kg/km

			Ω/km

			Cu

			Al

			Cu

			Al

			3×25

			6

			48.9

			4135

			3658

			0.727

			1.2

			3×35

			7

			51.3

			4658

			3991

			0.524

			0.868

			3×50

			8.4

			54.1

			5355

			4401

			0.387

			0.641

			3×70

			10

			58

			6311

			4976

			0.268

			0.443

			3×95

			11.5

			62.1

			7415

			5603

			0.193

			0.32

			3×120

			13

			65.6

			8479

			6190

			0.153

			0.253

			3×150

			14.5

			69.3

			9678

			6817

			0.124

			0.206

			3×185

			16.2

			73.2

			11093

			7564

			0.0991

			0.164

			3×240

			18.4

			80.4

			14191

			9613

			0.0754

			0.125

			3×300

			20.5

			85.4

			16457

			10735

			0.0601

			0.1

			3×400

			23.5

			93

			20188

			12558

			0.047

			0.0778

			3×500

			26.5

			100.3

			24606.3

			15455

			0.0366

			0.0605
