Copper Wire Screen Low Voltage Cable Single Core 0.6/1kV PVC Insulated Cable

Copper Wire Screen Low Voltage Cable Single Core 0.6/1kV PVC Insulated Cable
Copper Wire Screen Low Voltage Cable Single Core 0.6/1kV PVC Insulated Cable
Copper Wire Screen Low Voltage Cable Single Core 0.6/1kV PVC Insulated Cable Copper Wire Screen Low Voltage Cable Single Core 0.6/1kV PVC Insulated Cable

Large Image :  Copper Wire Screen Low Voltage Cable Single Core 0.6/1kV PVC Insulated Cable

Product Details:
Place of Origin: Hebei，China
Brand Name: Zhongdong
Certification: IEC,CE,ISO,TUV
Model Number: NYBY NAYBY
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Rolls, Wooden Drums, Steel Drums, Reels or customized
Delivery Time: 7-30 days based on different qty
Payment Terms: ,L/C,T/T
Supply Ability: 100KM/Week
Contact Now

Copper Wire Screen Low Voltage Cable Single Core 0.6/1kV PVC Insulated Cable

Description
Voltage: 0.6/1kV Insulation: XLPE
Jacket: PVC Feature: LSZH
Screen: Copper Wire Application: Underground, Overhead, Indoor, Mining And Power Distribution Etc
Highlight:

Low Voltage PVC Insulated Cable

,

Copper Wire Screen Low Voltage Cable

,

Low Voltage Cable Single Core

Copper Wire Screen Low Voltage Cable Single Core 0.6/1kV PVC Insulated Cable



Application


Copper-shielded low-voltage cables are widely used in environments requiring reliable power transmission with electromagnetic interference (EMI) protection



Construction


  1. Conductor:Circular, solid, compacted or sector shaped stranded Copper or aluminum
  2. Insulation:XLPE
  3. Filler:  Non-hygroscopic material
  4. Screen: Copper Wire
  5. Binder tape:: Non-hygroscopic material
  6. Sheath  PVC


Characteristics


  1. Test Voltage: 3.5kV 5min No Breakdown
  2. The ambient temperature for installation: ≥0℃.
  3. Maximum conductor temperature in normal operation:≤90℃.
  4. Max operating temperature of con. When cable short-circuited(5s maximum duration): 250℃.
  5. Permissible minimum bending radius:
  6. Single unarmoured cable: 20 x OD
  7. Multi-core unarmoured cable: 15 x OD
  8. Single armoured cable: 5 x OD
  9. Multi-core armoured cable: 12 x OD
  10. Note : OD=Overall Diameter of Cable



Specification



Nominal section area

Approx. overall diameter

Approx. weight of cable

Maximum DC resistance of the conductor

mm2

mm

kg/km

Ω/km





Cu

Al

20℃ Cu

20℃ Al

1×1.5 RE

5.8

49.3

–

12.1

–

1×2.5 RE

6.2

62.2

46.6

7.41

12.1

1×4 RE

7.1

86.4

61.6

4.61

7.41

1×6 RE

7.6

109.8

72.6

3.08

4.61

1×10 CC

8.6

156.7

94.8

1.83

3.08

1×16 CC

9.6

221

122

1.15

1.91

1×25 CC

11.2

324.1

169.4

0.727

1.2

1×35 CC

12.2

426.8

210.2

0.524

0.868

1×50 CC

14

586

276.6

0.387

0.641

1×70 CC

15.7

787.5

354.4

0.268

0.443

1×95 CC

17.7

1050.5

462.7

0.193

0.32

1×120 CC

19.3

1298.2

555.7

0.153

0.253

1×150 CC

21.3

1611.6

683.6

0.124

0.206

1×185 CC

23.6

1977.4

832.8

0.0991

0.164

1×240 CC

26.4

2537.7

1052.9

0.0754

0.125

1×300 CC

29.1

3146.2

1290.1

0.0601

0.1

1×400 CC

32.7

4140.8

1666

0.047

0.0778

1×500 CC

36.3

5142.2

2048.7

0.0366

0.0605

1×630 CC

40

6395.4

2497.6

0.0283

0.0469



Application Scenarios


Copper Wire Screen Low Voltage Cable Single Core 0.6/1kV PVC Insulated Cable 0Copper Wire Screen Low Voltage Cable Single Core 0.6/1kV PVC Insulated Cable 1Copper Wire Screen Low Voltage Cable Single Core 0.6/1kV PVC Insulated Cable 2
