Copper Core Solar Cable PVC Insulated PVC Sheathed Power Cable H1Z2Z2-K

Large Image : Copper Core Solar Cable PVC Insulated PVC Sheathed Power Cable H1Z2Z2-K

Product Details:

Place of Origin:	Hebei，China
Brand Name:	Zhongdong
Certification:	CCC,IEC,VDE,TUV,ISO
Model Number:	H1Z2Z2-K

Payment & Shipping Terms:

Minimum Order Quantity:	Negotiable
Price:	Negotiable
Packaging Details:	woodern drum
Delivery Time:	10work days
Payment Terms:	L/C,T/T
Supply Ability:	500KM/Week

Contact Now

Copper Core Solar Cable PVC Insulated PVC Sheathed Power Cable H1Z2Z2-K

Description

Insulation Material:	Xlpe	Jacket:	XLPO
Conductor Material:	Class 5 Tinned Copper	Application:	Construction
Core:	1 Core	Colour:	Black /Other Colours Available On Request
Highlight:	Copper Core Solar Cable PVC Insulated , H1Z2Z2-K PVC Sheathed Power Cable

Copper Core Control Cable PVC Insulated PVC Sheathed Control Cable H1Z2Z2-K

Application

DC Solar Cables

The interconnection between photovoltaic modules

Parallel connection between series and between modules and DC distribution boxes (combiner boxes)

Connection between DC distribution boxes and inverters.

AC Solar Cables

Connecting inverters to step-up transformers

The connection between the step-up transformer and the distribution equipment

The connection between power distribution equipment and the power grid or user

Copper Core Solar Cable PVC Insulated PVC Sheathed Power Cable H1Z2Z2-K 0

Description

‌Fire Resistance‌
‌Low Smoke and Toxicity‌:
‌Insulation Materials‌:
‌Durability‌:
‌Compliance‌:

Structure

Conductor: Tinned copper, offering excellent conductivity and corrosion resistance.

Insulation: Cross-linked polyethylene (XLPO) or similar material, providing high thermal and mechanical resistance.

Sheath: Halogen-free, flame-retardant material, ensuring safety and environmental compliance.

Electrical Characteristics

Cross section(mm²)	Conductor Construction(no/mm)	Conductor Stranded OD.max(mm)	Cable OD.(mm)	Approximate weight of cable kg/km	Max Conductor Resistance(Ω/km,20°C)
1×1.5	48/0.20	1.58	4.8	35	13.7
1×2.5	77/0.20	2.02	5.2	47	8.21
1×4	56/0.285	2.46	5.7	64	5.09
1×6	84/0.285	3.01	6.3	86	3.39
1×10	77/0.40	4.1	7.2	128	1.95
1×16	7×17/0.40	5.5	8.9	196	1.24
1×25	7×27/0.40	6.7	10.7	299	0.795
1×35	7×38/0.40	8.2	12.4	407	0.565
1×50	19×20/0.40	10.0	14.6	571	0.393
1×70	19×28/0.40	11.6	16.4	773	0.277
1×95	19×38/0.40	13.5	18.5	1024	0.210
1×120	24×38/0.40	14.4	19.8	1266	0.164
1×150	30×38/0.40	16.2	22.2	1584	0.132
1×185	37×38/0.40	18.2	25.0	1967	0.108
1×240	48×38/0.40	20.6	27.8	2518	0.0817
