STANDARD
IEC, BS, ICEA, ASTM, DIN
SPECIFICATION
|
ominal cross-sectional area mm2
|
Actual cross-sectional area mm2
|
Number of strands
|
Diameter
|
Approximate weight of cable
|
Nominal Breaking Load
|
Maximum DC Resistance at 20℃
|
|
|
Single wire
|
Conductor
|
|
mm
|
mm
|
kg/km
|
kN
|
Ω/km
|
|
10
|
10
|
7
|
1.35
|
4.05
|
27.4
|
1.95
|
2.8633
|
|
16
|
16
|
7
|
1.71
|
5.12
|
43.8
|
3.04
|
1.7896
|
|
25
|
25
|
7
|
2.13
|
6.4
|
68.4
|
4.5
|
1.1453
|
|
40
|
40
|
7
|
2.7
|
8.09
|
109.4
|
6.8
|
0.7158
|
|
63
|
63
|
7
|
3.39
|
10.2
|
172.3
|
10.39
|
0.4545
|
|
100
|
100
|
19
|
2.59
|
12.9
|
274.8
|
17
|
0.2877
|
|
125
|
125
|
19
|
2.89
|
14.5
|
343.6
|
21.25
|
0.2302
|
|
160
|
160
|
19
|
3.27
|
16.4
|
439.8
|
26.4
|
0.1798
|
|
200
|
200
|
19
|
3.66
|
18.3
|
549.7
|
32
|
0.1439
|
|
250
|
250
|
19
|
4.09
|
20.5
|
687.1
|
40
|
0.1151
|
|
315
|
315
|
37
|
3.29
|
23
|
867.9
|
51.97
|
0.0916
|
|
400
|
400
|
37
|
3.71
|
26
|
1102
|
64
|
0.0721
|
|
450
|
450
|
37
|
3.94
|
27.5
|
1239.8
|
72
|
0.0641
|
|
600
|
600
|
37
|
4.15
|
29
|
1377.6
|
80
|
0.0577
|
|
560
|
560
|
37
|
4.39
|
30.7
|
1542.9
|
89.6
|
0.0515
|
|
630
|
630
|
61
|
3.63
|
32.6
|
1738.3
|
100.8
|
0.0458
|
|
710
|
710
|
61
|
3.85
|
34.6
|
1959.1
|
113.6
|
0.0407
|
|
800
|
800
|
61
|
4.09
|
36.8
|
2207.4
|
128
|
0.0361
|
|
900
|
900
|
61
|
4.33
|
39
|
2483.3
|
144
|
0.0321
|
|
1000
|
1000
|
61
|
4.57
|
41.1
|
2759.2
|
160
|
0.0289
|
|
1120
|
1120
|
91
|
3.96
|
43.5
|
3093.5
|
179.2
|
0.0258
|
|
1250
|
1250
|
91
|
4.18
|
46
|
3452.6
|
200
|
0.0231
|
|
1400
|
1400
|
91
|
4.43
|
48.7
|
3866.9
|
224
|
0.0207
|
|
1500
|
1500
|
91
|
4.58
|
50.4
|
4143.1
|
240
|
0.0193
|
