N2XS(F)2Y N2XSY Four Core MV Power Cable With Copper Conductor PVC Insulated

Large Image : N2XS(F)2Y N2XSY Four Core MV Power Cable With Copper Conductor PVC Insulated

Product Details:

Place of Origin:	Hebei，China
Brand Name:	Zhongdong
Certification:	IEC,CE,ISO,TUV

Payment & Shipping Terms:

Minimum Order Quantity:	Negotiable
Price:	Negotiable
Packaging Details:	Rolls, Wooden Drums, Steel Drums, Reels or customized
Delivery Time:	7-30 days based on different qty
Payment Terms:	,L/C,T/T
Supply Ability:	100KM/Week

Contact Now

N2XS(F)2Y N2XSY Four Core MV Power Cable With Copper Conductor PVC Insulated

Description

Voltage:	0.6/1kV	Insulation:	PVC
Jacket:	PVC	No Of Core:	3

N2XS(F)2Y N2XSY Four Core MV Power Cable With Copper Conductor PVC Insulated

APPLICATION

The medium-voltage power cable is widely used in industrial and utility electrical networks. Its primary applications include:

‌Power distribution systems‌: Transmits electrical energy in underground or cable-tray installations.
‌Industrial plants‌: Supplies power to heavy machinery, transformers, and substations.
‌Renewable energy projects‌: Integrates into wind farms, solar parks, and grid connections requiring robust shielding.
‌Urban infrastructure‌: Deployed in underground networks for public utilities, hospitals, and commercial complexes.
‌High electromagnetic interference (EMI) environments‌: Ideal for areas with strong EMI due to its double-layer shielding.

CONSUCTRUCTION

Conductor:Class 2 Stranded Copper
Conductor Screen:Semi-conductive material
Insulation: XLPE (Cross-Linked Polyethylene)
Insulation Screen:Semi-conductive material (bonded)
Longitudinal Water blocking Semi-conductive swellable tape
ScreenZ: Copper wires and copper tape
Outer Sheath MDPE (Medium Density Polyethylene)

N2XS(F)2Y N2XSY Four Core MV Power Cable With Copper Conductor PVC Insulated 0

SPECIFICATION

	NO. OF CORES	NOMINAL CROSS SECTIONAL AREA mm²		NOMINAL CONDUCTOR DIAMETER mm	NUMBER WIRES CONDUCTOR mm	NOM. THICKNESS SEMI-CON. LAYER mm		NOMINAL INSULATION THICKNESS mm	MINIMUM INSULATION THICKNESS mm	NOMINAL DIAMETER OVER INSULATION mm
	NO. OF CORES	Conductor	Screen	NOMINAL CONDUCTOR DIAMETER mm	NUMBER WIRES CONDUCTOR mm	INNER	OUTER	NOMINAL INSULATION THICKNESS mm	MINIMUM INSULATION THICKNESS mm	NOMINAL DIAMETER OVER INSULATION mm
N2XS(F)2Y 6/10 (12)kV	1	50	16	8.1	10 x 2.62	0.5	0.4	3.4	2.96	16.3
	1	70	16	9.7	14 x 2.62	0.5	0.4	3.4	2.96	17.9
	1	95	16	11.4	19 x 2.62	0.5	0.4	3.4	2.96	19.6
	1	120	16	12.7	19 x 2.97	0.5	0.4	3.4	2.96	20.9
	1	150	25	14.5	19 x 3.20	0.5	0.4	3.4	2.96	22.7
	1	185	25	15.9	27 x 2.62	0.5	0.4	3.4	2.96	24.1
	1	240	25	18.6	48 x 2.62	0.5	0.4	3.4	2.96	26.8
	1	300	25	20.7	61 x 2.62	0.5	0.4	3.4	2.96	28.9
	1	400	35	23.5	61 x 2.97	0.5	0.4	3.4	2.96	31.7
	1	500	35	26.5	61 x 3.29	0.5	0.4	3.4	2.96	34.7
	1	630	35	30.2	61 x 3.80	0.5	0.4	3.4	2.96	38.9
N2XS(F)2Y 12/20 (24)kV	1	50	16	8.1	10 x 2.62	0.5	0.4	5.5	4.85	20.3
	1	70	16	9.7	14 x 2.62	0.5	0.4	5.5	4.85	21.9
	1	95	16	11.4	19 x 2.62	0.5	0.4	5.5	4.85	23.6
	1	120	16	12.7	19 x 2.97	0.5	0.4	5.5	4.85	24.9
	1	150	25	14.5	19 x 3.20	0.5	0.4	5.5	4.85	26.7
	1	185	25	15.9	27 x 2.62	0.5	0.4	5.5	4.85	28.1
	1	240	25	18.6	48 x 2.62	0.5	0.4	5.5	4.85	30.8
	1	300	25	20.7	61 x 2.62	0.5	0.4	5.5	4.85	32.9
	1	400	35	23.5	61 x 2.97	0.5	0.4	5.5	4.85	35.7
	1	500	35	26.5	61 x 3.29	0.5	0.4	5.5	4.85	38.7
	1	630	35	30.2	61 x 3.80	0.5	0.4	5.5	4.85	42.9
N2XS(F)2Y 18/30 (36)kV	1	50	16	8.1	10 x 2.62	0.5	0.4	8	7.1	25.1
	1	70	16	9.7	14 x 2.62	0.5	0.4	8	7.1	26.7
	1	95	16	11.4	19 x 2.62	0.5	0.4	8	7.1	28.4
	1	120	16	12.7	19 x 2.97	0.5	0.4	8	7.1	29.7
	1	150	25	14.5	19 x 3.20	0.5	0.4	8	7.1	31.5
	1	185	25	15.9	27 x 2.62	0.5	0.4	8	7.1	32.9
	1	240	25	18.6	48 x 2.62	0.5	0.4	8	7.1	35.6
	1	300	25	20.7	61 x 2.62	0.5	0.4	8	7.1	37.7
	1	400	35	23.5	61 x 2.97	0.5	0.4	8	7.1	40.5
	1	500	35	26.5	61 x 3.29	0.5	0.4	8	7.1	43.5
	1	630	35	30.2	61 x 3.80	0.5	0.4	8	7.1	47.7

ABOUT US

N2XS(F)2Y N2XSY Four Core MV Power Cable With Copper Conductor PVC Insulated 1

APPLICATION

WHY CHOOSE US

PARTNER

N2XS(F)2Y N2XSY Four Core MV Power Cable With Copper Conductor PVC Insulated 4

FAQ

1. What does "N2XS(F)2Y" stand for in cable nomenclature?
• N: German standard (DIN VDE 0276)
• 2X: XLPE (cross-linked polyethylene) insulation
• S: Copper wire + copper tape shielding
• (F): Longitudinal water-blocking feature
• 2Y: PE (polyethylene) outer sheath
2. What are the typical voltage ratings for N2XS(F)2Y cables?
• Standard: 6/10 kV (12 kV max)
• Optional: 12/20 kV (24 kV max) and 18/30 kV (36 kV max)
3. Where are these cables commonly installed?
• Underground burial (with mechanical protection)
• Cable ducts, tunnels, and indoor power stations
• Industrial plants and distribution networks
4. What international standards apply to N2XSY cables?
• IEC 60502-2 (medium voltage cables)
• VDE 0276-603 (German standard)
• HD 620 S1 (European harmonized standard)
5. What is the temperature range for operation?
• Operating: -40°C to +90°C
• Short-circuit: Up to +250°C (max 5 sec)
6. How is the cable shielded?
• Copper wire braid
• Helically wound copper tape (reverse lay)
7. What are the bending radius requirements?
• Dynamic installation: ≥15× cable diameter
• Fixed installation: ≥12× cable diameter
8. Does the "(F)" variant offer special features?
Yes: Longitudinal water-blocking (swelling tapes/yarns), Enhanced moisture resistance for underground use
9. What conductor materials are available?
• Copper: EN 60228 Class 2 stranded
• Aluminum: Optional for cost-sensitive projects
10. How is the cable protected against corrosion?
• Galvanized steel wire armor (optional for NA2XS(F)2Y variant)
• PE sheath provides chemical/UV resistance
